Case
Study

HDRM for μHETsat ESA + ASI

HDRM for μHETsat ESA + ASI

ARQUIMEA's HDRM and DEM (deployment mechanism) proved to be the right solution for the solar array deployment for the ESA Project μHETsat microsatellite.

SAM (Mobile Measurement System) for ANDRA

SAM (Mobile Measurement System) for ANDRA

SAM is a high-precision robot that performs different types of measurements inside High Level disposal cell casing which has been designed for ANDRA. The system shown an excellent behavior and was delivered succesfully in due time and form.

H2020 REACT for IOD innovative program

H2020 REACT for IOD innovative program

European Commission under the Horizon 2020 program aims to reduce the dependence from non‐European sources on a critical space technology. Thus, ARQUIMEA's REACT developed three different HDRMs (5 KN, 15 KN and 35KN) and proved their qualification.

HDRM REACT 15KN for JUICE – ESA Mission

HDRM REACT 15KN for JUICE – ESA Mission

JUICE (JUpiter ICy Moons Explorer) is an ESA Mission where ARQUIMEA proposed the use of their space-qualified release nut REACT 15KN extended operation temperature range and proved to be the optimal solution.

GEO-SCAU FPGA for EUTELSAT’s QUANTUM satellite

GEO-SCAU FPGA for EUTELSAT’s QUANTUM satellite

ARQUIMEA implemented the required logic into FPGAs which were assembled in the GEO-SCAU system and the EUTELSAT QUANTUM satellite completed the qualification phase. The FPGA firmware hardware validation done at AIRBUS facilities and successfully

MAQUETTE for ANDRA

MAQUETTE for ANDRA

MAQUETTE is a turnkey project (engineering, procurement, construction, installation, operation and maintenance) for ANDRA which showed an excellent behavior and observations pointed out that the rock cracking was reached.

REDSAT ASICs for ELSA Antenna

REDSAT ASICs for ELSA Antenna

REDSAT ASIC for Electronically Steerable Antenna (ELSA) is the first space microelectronics project awarded to ARQUIMEA which radiation characterization ands qualification were successful. Thousands of flight models were selected from the WAT ...

PRE2POS GIMBAL for H2020

PRE2POS GIMBAL for H2020

ARQUIMEA's PRE2POS Gimbal is the right solution for the target applications in small sats. It is a standard product, cost affordable and which successfully delivery in due time and form of the EQM model.

QUANTUM ASIC ARQ-RSB02 for ELSA+ Antenna

QUANTUM ASIC ARQ-RSB02 for ELSA+ Antenna

ARQ-RSB02 is a Full CMOS device designed by ARQUIMEA using the DARE180 rad-hard standard cell library under the QUANTUM project. The new digital ASIC allows controlling and managing the RF subassemblies of the ELSA+ phased array active antenna ...

HDRM REACT 15KN for H2020 Large European Antenna (LEA)

HDRM REACT 15KN for H2020 Large European Antenna (LEA)

LEA project was looking for a fully European solution for the release nuts part of the HDRM. They had to be used for both the release of the arm and the deployable reflector.ARQUIMEA proposed the use of their space-qualified release nut REACT ...

Rad-hard Ethernet PHY transceiver 10BASE-T/100BASE-TX

Rad-hard Ethernet PHY transceiver 10BASE-T/100BASE-TX

The development of a complex mixed-signal product like SEPHY based on the IEEE802.3 commercial Ethernet standard, relies not only on its implementation (trade-off between rad-hard design and performances) but also on a good understanding of the ...

HDRM for the first commercial microsatellite ESAIL

HDRM for the first commercial microsatellite ESAIL

ARQUIMEA solution for ESAIL project consisted of four devices per solar array, so a total of eight Flight Models plus one spare unit were provided to LuxSpace.

ESA – RTG4 FPGA SEE Mitigation

ESA – RTG4 FPGA SEE Mitigation

ARQUIMEA led a consortium that carried out the design of rad-hard integrated circuits running on the RTG4, as well as verification tools to prove the equivalence of the designs with and without SEE mitigation techniques.

ARAS – Adaptative Robotic Algorithms for Sanding

ARAS – Adaptative Robotic Algorithms for Sanding

The solution is based on a set of libraries adaptable to the cobot programming language that allows a fast and easy parametrization of the desired sanding or polishing process to be done. The operator just provides the desired parameters of ...

HDRM for H2020 ALTAIR

HDRM for H2020 ALTAIR

ARQUIMEA implemented a solution based on the company’s HDRM, together with an electronic system for the controlled actuation of the devices. The system is formed by two REACT 5kN Standard Temperature units and the electronics for synchronized ...
